Heavy Duty Roller Chain for Street Motorcycle & Off-Road Motorcycle

Request a Quote

Optimum durability can be achieved with our custom-made reinforced non-sealed motorcycle chains using seamless steel pipe, along with all the benefits of our standard chains.

Features

Exceptional durability because of the seamless steel pipe
Long miles thanks to high-quality material, seamed steel pipe and 20CrMnMo bush
Resistance to impact from the solid 10-grade-steel-made roller
Increased tensile strength from 30 CrMnTai pin
Good fatigue resistance due to 45Mn plates
Wear assistance delivered by highly adhesive lubricants

Application

Street motorcycles and off-road motorcycle with heavy dirt

Specifications

DIN ISO Chain No.	Pitch		Bush type	Roller Dia max mm	Width min mm	Pin Dia max mm	Plate Thickness mm	h2 max mm	Pin Length max mm	Tensile KN	A.T.S KN	Weight kg/m
DIN ISO Chain No.	mm	inch	Bush type	Roller Dia max mm	Width min mm	Pin Dia max mm	Plate Thickness mm	h2 max mm	Pin Length max mm	Tensile KN	A.T.S KN	Weight kg/m
428S	12.70	1/2"	Solid	8.51	7.94	4.45	1.85	11.80	18.40	20.60	21.36	0.69
428HS	12.70	1/2"	Solid	8.51	7.94	4.45	2.03	11.80	18.75	23.80	24.72	0.79
520S	15.88	5/8"	Solid	10.14	6.35	5.08	2.03	15.00	19.10	26.50	31.80	0.89
530S	15.88	5/8"	Solid	10.14	9.53	5.08	2.03	15.00	22.10	26.50	31.80	1.06

Ever since foundation, innovation and high quality have been our main focus and pride as a leading company in manufacturing and developing motorcycle chains and industrial chains. Made of premium alloy (45Mn, 20Mn, 30CrMnTi, M10) in high-precision molds, our chains have gone through rigorous heat treatment and comprehensive quality control. Coupled with fully automated production line and technical team with extensive knowledge, our motorcycle chains and industrial chains are in parallel with the chains from top manufacturers in core indexes such as initial elongation, fatigue resistance and tensile strength.
